Industrial Heavy Duty Pressure Gauge

Ritherm Industrial heavy duty pressure gauge

Applications

1120 series Industrial heavy duty pressure gauge typically for for use in quality industry and suitable for gases and liquids that do not attack the brass measuring system., and pressure reducers or valves.

Ritherm Industrial heavy duty pressure gauge

Model 1120 are made of Black steel case and bayonet bezel, acrylic window, brass inside and connection. The nominal dial size is 100mm and 150mm.

It is a bourdon tube pressure gauge, with stainless steel bourdon tube and movement.

The accuracy is 1.6% full scale.

The process connection is 1/4"NPT male thread, Special thread is for option.

Pressure range from 0 to 400bar.

The ambient temperature is suitable for -40+70 deg C.

The working temperature for standard use is -20+70 deg C.

Industrial heavy duty pressure gauge has 1 year lifetime guarantee.

Ritherm is the brand of Rising Instrument. Rising Instrument is one of the top quality pressure gauge manufacturers and suppliers in China. We have been specialized in pressure gauges since 2003. Our products have a good quality, which is produced strictly according to EN 837 standard and ANSI B40.1 standard.
